TTO DATAFLEX 6320

The DataFlex® 6320 is a thermal transfer coding solution for flexible packaging applications requiring high quality variable printing at moderate print speeds.

The Videojet DataFlex® 6320 industrial thermal transfer printer is a available in two print widths, 32 mm and 53 mm, to provide the best combination of printhead and ribbon width to deliver the most cost effective solution for your application requirements. Engineered for applications such as vertical form fill and seal, the DataFlex 6320 delivers print speeds up to 250 packs/min.





Uptime Advantage



  • Clutchless ribbon drive maintains consistent ribbon tension,

virtually eliminating ribbon breaks and ribbon related downtime

  • Simplest ribbon cassette design on the market, that makes ribbon

replenishment fast, ensuring the coder is back on-line and coding

with minimum impact to production





Built-in productivity



  • Longer 1200m ribbon length provides more throughput of coded

products between ribbon changes

  • A wide ranging selection of ribbons, designed specifically to meet

the challenges of flexible packaging applications

  • Patented bi-directional ribbon drive helps ensure that the absolute

minimum ribbon is used during each print cycle, providing more

prints per roll of ribbon

  • Consistent 0.02” (0.5mm) gap between prints helps ensure highest

ribbon efficiency and minimum waste





Code Assurance



  • Advanced coder software virtually eliminates set-up errors
  • Simple message selection reduces the potential for operator errors
  • Range of customer selectable rules and permissions that help to

prevent operator error with the printed code





Simple usability



  • Seamless mechanical integration with a range of OEM equipment
  • Comprehensive communications package for host packaging

and control

  • Easy to use interface with 8.4″ icon based color touch screen
  • Intuitive design features make training and operation quick

and easy

Specification32 mm53 mm
Printer ModeIntermittent and Continuous MotionIntermittent and Continuous Motion
Print Gap0.5 mm (0.020 in)0.5 mm (0.020 in)
Maximum Ribbon Length1200 m (3937 ft)1200 m (3937 ft)
Ribbon WidthsMin: 20 mm (0.8 in)
Max: 55 mm (2.16 in)
Min: 20 mm (0.8 in)
Max: 55 mm (2.16 in)
Continuous Mode:
Maximum Print Area
(Width x Length)
32 x 200 mm
(2.08 x 7.87 in)
53 x 200 mm
(2.05 x 7.87 in)
Maximum Print Speed750 mm/sec (29.53 in/sec)750 mm/sec (29.53 in/sec)
Minimum Print Speed0 mm/sec (0 in/sec)0 mm/sec (0 in/sec)
Intermittent Mode:
Maximum Print Area
(Width x Length)
32 x 75 mm
(1.26 x 2.95 in) RH option
32 x 68 mm
(1.26 x 2.68 in) LH option
53 x 75 mm
(2.08 x 2.95 in) RH option
53 x 68 mm
(2.08 x 2.68 in) LH option
Maximum Print Speed750 mm/sec (29.53 in/sec)750 mm/sec (29.53 in/sec)
Minimum Print Speed50 mm/sec (1.96 in/sec)50 mm/sec (1.96 in/sec)
Bar Code PrintingYes, as variable informationYes, as variable information
Estimated Maximum Throughput (Single Line Code, Continuous Mode)250 packs/min250 packs/min
Standard User InterfaceCLARiTY™ 8.4 inch SVGA color LCD touchscreenCLARiTY™ 8.4 inch SVGA color LCD touchscreen
Master/Follower Capability (Up to 4 Printers Controlled by One User Interface)OptionalOptional
Standard CommunicationRS232, Ethernet, USB Memory Stick, select ZPL command emulation, Binary and ASCII commsRS232, Ethernet, USB Memory Stick, select ZPL command emulation, Binary and ASCII comms
Web Browser CapabilityYesYes
