ADVANCED CAPABILITIES
VIDEOJET 1550 small character inkjet coder is a highly flexible printer designed for a range of packaging applications. Engineered to provide the highest uptime available, the 1550 meets a range of medium-duty coding applications and also includes advanced features that help reduce errors and rework and improve productivity.
Speed without compromising quality:
- Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print
- Print 1 to 5 lines of print for a range of coding needs:
- Single line max speed = 279 m/min (914 ft/min)
- Dual line max speed = 81 m/min (267 ft/min)
- Tri-line max speed = 36 m/min (119 ft/min)
Engineered for extended runs; Uptime Advantage via:
- CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down
- Long run time between preventive maintenance; up to 12,000 hour core life
- Internal pump means no external air, minimizing potential for contaminants to enter ink stream
- Auto cleaning printhead for fast start-ups, even after extended shutdowns
No mess, no waste fluid delivery:
- Make-up consumption as low as 2.4 ml/hour
- Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used
On-board Code Assurance to help prevent coding mistakes:
- Advanced software minimizes and mistake-proofs operator inputs to the coding and marking process to help reduce errors
- Operator inputs are governed by rules which simplifies choices via field prompts, drop-down menus, calendar displays and predefined formats to help ensure correct entries
Built-in Productivity tools to keep your lines operational:
- Bright, 10.4 inch color touchscreen interface that provides real-time fluid levels, maintenance alerts, print jobs and other operational information
- Instant fault information is displayed to get your printer and line running again – fast
- Drill down into Printer Availability data to discover technical and operational causes of downtime, get to the root cause of downtime events and fix them for good
SPECIFICATION
| Specification | Value |
| Printheads | 1 |
| Inks | Dye Based |
| Maximum Lines of Print | 5 |
| Maximum Line Speed (1) | 279 m/min (914 ft/min) |
| Environmental Protection | IP55 (IP65 optional) |
| Core Life (Maintenance Interval) | Up to 12,000 hours |
| Umbilical Length | 3 m (9.8 ft) optional 6 m (19.6 ft) |
| Message Storage Capability | 250 |
| Smart Cartridge™ | Included |
| Plug and Play Printhead Modules | Included |
| USB | Included |
| Communications | Ethernet (standard) Clarisoft/Clarinet® via ethernet Message management via USB |
| Positive Air / CleanFlow™ | Included |
| Expanded I/O Ports and Control | # |
| Display (User Interface) | CLARiTY ® based 10.4 inch color touchscreen |
# Optional
(1) Based upon single line, 10 characters per inch
APPLICATIONS & VIDEO
Dairy
Fruits and Vegetables
Baked Goods and Cereal
OTHER INDUSTRY APPLICATIONS:
- Cosmetics, Personal and Home Care
- Salty Snacks
- Candy and jam
- Animal feed and pets
- Automotive and Aviation Technology
- Seafood
Meat and Poultry
Frozen Prepared Meals
Wire, Cable and Pipe
Orion Sterling –
Print expiration date and batch code on paper and plastic packaging. The machine runs stably and at high speed while the letters are still clear. Low ink consumption, easy to operate, quick ink replacement. Used for more than a year without any major problems.
