DGC SERIES RINSER-FILLER-CAPPER – 3 IN 1 PRODUCTION LINE
DGC series rinser-filler-capper hot filling monobloc is a high efficient liquid packing machine which is a great combination of bottle washing machine, low vacuum pressure filling machine and capping machine. Empty bottles are fed into the rinsing machine by an air conveyor, then be turned over and washed inside by the nozzles. After dripping, bottles are fed to the filling machine for high quality filling. At last, the capping machine is used for safe and reliable capping of these bottles.
- In order to meet the related food hygiene requirements, all parts in contact with liquid are manufactured by quality stainless steel, for instance, the filling valves are made of stainless steel 316.
- Adopting low vacuum pressure filling method, our juice, tea drink production line achieves high filling speed, high filling precision and great filling quality at the same time.
- Bottles are fed by the air conveyor and transported by clipping the bottle neck and put out by normal conveyor chain. Hence, it is easy and convenient to change bottle size.
- The use of “PICK, PLACE” capping system ensures reliable capping, the adoption of magnetic torque structure makes it convenient to adjust the torque.
- This 3-in-1 monobloc effectively shortens the process of washing, filling and capping, which is time saving and helps keep the machine clean and sanitary.
- Production cost is significantly reduced due to the high efficiency of this machine.
- This equipment is controlled by frequency conversion motor+PLC+man-machine interface. So production speed, shift production and failure alarm etc. are displayed on the screen for simple operation.
Specifications of Rinser-Filler-Capper Hot Filling Monobloc
|Model||Number of Bottle Rinsing Clip||Number of Filling Valve||Number of Capping Head||Capacity(bpm)||Bottle Size||Outline Dimensions (mm)||Weight (Kg)||Remark|
|Diameter (mm)||Height (mm)||Volume (ml)|
|DGC08||24||24||8||6000-10000||Φ60-Φ96||180-315||350-1500||2800×2400 x2600||6000||All-in-one Type|
|DGC10||32||32||10||10000-14000||Φ60-Φ96||180-315||350-1500||3300×3000 x2700 25002500 3085||7200||All-in-one Type|
|DGC12||40||40||12||14000-18000||Φ60-Φ96||180-315||350-1500||3900×3180 x2700||9000||All-in-one Type|
|DGC15||50||50||15||18000-20000||Φ60-Φ96||180-315||350-1500||5300×4200 x2900||10000||All-in-one Type|
|DGC15||60||60||15||20000-24000||Φ60-Φ96||180-315||350-1500||5700×4600 x2900||12000||All-in-one Type|
|DGC18||72||72||18||22000-28000||Φ60-Φ96||180-315||350-1500||6600×5100 x2900||15000||All-in-one Type|
