ADVANCED CAPABILITIES
TTO DATAFLEX PLUS 6420 industrial thermal transfer printer provides high speed printing for flexible packaging applications. The 6420 is available in two print widths, 53 mm and 107 mm, to meet your specific application needs.
Uptime Advantage
- Clutchless ribbon drive maintains consistent ribbon tension, virtually eliminating ribbon breaks and ribbon related downtime
- Simplest ribbon cassette design on the market, that makes ribbon replenishment fast, ensuring the coder is back on-line and coding with minimum impact to production
Code Assurance
- Advanced coder software virtually eliminates set-up errors
- Simple message selection reduces the potential for operator errors
- Range of customer selectable rules and permissions that help to prevent operator error with the printed code
Simple usability
- Seamless mechanical integration with a range of OEM equipment
- Comprehensive communications package for host packaging and control
- Easy to use interface with 8.4” icon based color touch screen
- Intuitive design features make training and operation quick and easy
Built-in productivity
- Longer 1200m ribbon length provides more throughput of coded products between ribbon changes
- A wide ranging selection of ribbons, designed specifically to meet the challenges of flexible packaging applications
- Patented bi-directional ribbon drive helps ensure that the absolute minimum ribbon is used during each print cycle, providing more prints per roll of ribbon
- Consistent 0.02” (0.5mm) gap between prints helps ensure highest ribbon efficiency and minimum waste
SPECIFICATION
| Specification | 53 mm | 107 mm |
| Printer Mode | Intermittent and Continuous Motion | Intermittent and Continuous Motion |
| Print Gap | 0.5 mm (0.020 in) | 0.5 mm (0.020 in) |
| Maximum Ribbon Length | 1200 m (3937 ft) | 700 m (2297 ft) |
| Ribbon Widths | Min: 20 mm (0.8 in) Max: 55 mm (2.17 in) |
Min: 20 mm (0.8 in) Max: 110 mm (4.33 in) |
| Continuous Mode: | ||
| Maximum Print Area (Width x Length) |
53 x 200 mm (2.08 x 7.87 in) |
107 x 200 mm (4.33 x 7.87 in) |
| Maximum Print Speed | 1000 mm/sec (39.37 in/sec) | 800 mm/sec (31.50 in/sec) |
| Minimum Print Speed | 0 mm/sec (0 in/sec) | 0 mm/sec (0 in/sec) |
| Intermittent Mode: | ||
| Maximum Print Area (Width x Length) |
53 x 75 mm (2.08 x 2.95 in) RH option 53 x 68 mm (2.08 x 2.68 in) LH option |
107 x 75 mm (4.21 x 2.95 in) RH option 107 x 68 mm (4.21 x 2.68 in) LH option |
| Maximum Print Speed | 800 mm/sec (31.50 in/sec) | 700 mm/sec (27.56 in/sec) |
| Minimum Print Speed | 50 mm/sec (1.96 in/sec) | 50 mm/sec (1.96 in/sec) |
| Bar Code Printing | Yes, as variable information | Yes, as variable information |
| Estimated Maximum Throughput (Single Line Code, Continuous Mode) | 400 packs/min | 200 packs/min |
| Standard User Interface | CLARiTY™ 8.4 inch SVGA color LCD touchscreen | CLARiTY™ 8.4 inch SVGA color LCD touchscreen |
| Master/Follower Capability (Up to 4 Printers Controlled by One User Interface) | Optional | Optional |
| Standard Communication | RS232, Ethernet, USB Memory Stick, select ZPL command emulation, Binary and ASCII coms | RS232, Ethernet, USB Memory Stick, select ZPL command emulation, Binary and ASCII coms |
| Web Browser Capability | Yes | Yes |
APPLICATIONS & VIDEO
- Fruits and Vegetables
- Salty Snacks
- Dairy
- Candy and Confectionery
- Baked Goods and Cereal
- Fish and Seafood
Additional Applications
- Building Materials
- Cosmetics, Personal and Home Care
- Pet Food and Animal Feed
Alessia Michel –
I use Videojet 6420 to print date and batch code on film packaging, the print is clear, not blurred. The machine runs stably, high speed, saving ribbon. Changing ribbon is quick, simple operation, very suitable for continuous packaging line.
