ADVANCED CAPABILITIES
Low volume operations running less than 5 days per week can benefit from the Videojet 1040 Continuous Inkjet Printer. Experience high quality print and automatic maintenance procedures to keep your printer running optimally at great value.
Speed without compromising quality:
- Apply highly legible codes up to 7.5mm in height onto primary products and outer case packaging
- Clean and crisp codes to improve brand reputation and increase consumer confidence
- Accurate drop placement technology provides precise character formation in multiple printing environments at multiple speeds
Engineered to keep your line running:
- Auto-cleaning printhead delivers up to 12 days of continuous use without cleaning
- Dynamic Calibration™ automatically adjusts printing parameters for changing temperature or humidity conditions without manual operator intervention
- Reliable start-up and print following extended shutdown up to two days
No mess, no waste fluid delivery:
- Advanced fluid management reduces makeup consumption to as low as 2.4 ml/hr
- Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used
Simple Usability via Videojet standard CIJ interface:
- Intuitive 7” color touchscreen is easy to operate with fewer steps to input codes, requiring less operator training
- Visual job selection and layout preview helps operator ensure the correct codes will be printed
- Automatic date and time insert function reduces the risk of waste and rework from incorrect codes
SPECIFICATION
| Specification | Value |
| Printheads | 1 (60 micron) |
| Inks | Dye Based |
| Maximum Lines of Print | 2 |
| Environmental Protection | IP43 Standard |
| Maintenance Interval | 3000 hours (filter exchange) |
| Umbilical Length | 2m (6.6”) |
| Message Storage Capability | 15 |
| Smart Cartridge TM | Included |
| Plug and Play Printhead Modules | Included |
| USB | Included |
| Communications | Product Detect Input |
| Dynamic Calibration | Yes |
| Display (User Interface) | 7” LCD Touch Screen |
APPLICATIONS & VIDEO
Other Packaged Foods
Beverage
Cosmetics, Personal and Home Care
Construction materials
Kennedy –
The print is clear and even. The machine is compact, easy to install, and has low ink consumption. Simple operation, suitable for small and medium-sized production lines.
