Máy in truyền nhiệt TTO - Videojet 6210 VJ6210

Videojet TTO 6210

5.00 trên 5 dựa trên 1 đánh giá

The TTO 6210 delivers maximum reliability and efficiency for marking variable, high resolution images on flexible packaging and labels — at an affordable price.

Danh mục: Industrial inkjet printer, Thermal Transfer Overprinter (TTO)

Mô tả
Đánh giá (1)

Mục lục

ADVANCED CAPABILITIES

The Videojet TTO 6210 offers a proven and cost-effective solution for users ready to migrate to a digital solution from a non-digital solution such as hot stamp or roller coders. It is ideal for lower speed intermittent and continuous motion flexible packaging applications. The 6210 is well-suited for variable data coding in the snack food, bakery, confectionery, frozen and refrigerated foods, bagged fresh vegetables and dried fruits markets.

Uptime Advantage

Clutchless ribbon drive maintains consistent ribbon tension, virtually eliminating ribbon breaks and ribbon related downtime
Simple ribbon cassette design makes ribbon replenishment fast
600 meter ribbon length requires less frequent ribbon changes than hot stamp or other competitive TTO systems

Built-in productivity

Bi-directional ribbon drive allows unused ribbon to be recaptured after each print
Delivers more prints per roll and a low cost of ownership
Offers 300 dpi print resolution for high quality codes up to 32 mm (1.26 in) wide at speeds up to 125 packs/minute

Code Assurance

Advanced coder software virtually eliminates set-up errors
Range of customer selectable rules and permissions along with simple message selection reduce the potential for operator errors
WYSIWYG image display reduces set up errors

Simple usability

Intuitive, graphical user interface with 5.7-inch color touchscreen incorporates easy to learn icon-based controls, helping to make set-up fast and easy
Variable date and time fields are automatically updated eliminating the time and effort spent changing stamps

SPECIFICATION

Specification	Value
Printer Mode	Intermittent and Continuous Motion
Print Gap	1 mm (0.039 in)
Maximum Ribbon Length	600 m (1968 ft)
Ribbon Widths	22 mm (0.87 in) and 33 mm (1.30 in)
Continuous Mode:
Maximum Print Area (Width x Length)	32 x 40 mm (1.26 x 1.57 in)
Maximum Print Speed	500 mm/sec (19.69 in/sec)
Minimum Print Speed	40 mm/sec (1.57 in/sec)
Intermittent Mode:
Maximum Print Area (Width x Length)	32 x 34 mm (1.26 x 1.34 in)
Maximum Print Speed	200 mm/sec (7.87 in/sec)
Minimum Print Speed	50 mm/sec (1.97 in/sec)
Bar Code Printing	Only as a logo
Estimated Maximum Throughput (Single Line Code, Continuous Mode)	Approximately 125 packs/min
Standard User Interface	CLARiTY™ 5.7 inch SVGA color LCD touchscreen
Standard Communication	RS232, USB Memory Stick
